ARRI ZEISS MASTER PRIMES
The master family of lenses are fast and have an optical performance surpassing that of all standard speed primes. The whole family has been developed by ARRI and Carl Zeiss to enable shots that would have been considered impossible before. They are the perfect combination for high-end film or digital PL mount cine cameras.
— LENS SPECIFICATIONS —
| FOCAL LENGTH |
SPEED | CLOSE FOCUS |
WEIGHT | LENGTH | FRONT DIAMETER |
MOUNT | COVERAGE |
|---|---|---|---|---|---|---|---|
| 12mm | T1.3 | 16" | 6.4 lb | 7.8" | 156mm | PL | S35 |
| 14mm | T1.3 | 14" | 5.3 lb | 6.8" | 114mm | PL | S35 |
| 16mm | T1.3 | 14" | 4.8 lb | 6.0" | 114mm | PL | S35 |
| 18mm | T1.3 | 14" | 4.8 lb | 6.0" | 114mm | PL | S35 |
| 21mm | T1.3 | 14" | 5.3 lb | 6.0" | 114mm | PL | S35 |
| 25mm | T1.3 | 14" | 5.1 lb | 6.0" | 114mm | PL | S35 |
| 27mm | T1.3 | 14" | 4.8 lb | 6.0" | 114mm | PL | S35 |
| 32mm | T1.3 | 14" | 5.1 lb | 6.0" | 114mm | PL | S35 |
| 35mm | T1.3 | 14" | 4.8 lb | 6.0" | 114mm | PL | S35 |
| 40mm | T1.3 | 16" | 5.1 lb | 6.0" | 114mm | PL | S35 |
| 50mm | T1.3 | 20" | 5.9 lb | 6.0" | 114mm | PL | S35 |
| 65mm | T1.3 | 2' 3" | 5.7 lb | 6.0" | 114mm | PL | S35 |
| 75mm | T1.3 | 2' 9" | 6.2 lb | 6.0" | 114mm | PL | S35 |
| 100mm | T1.3 | 3' 6" | 6.4 lb | 6.0" | 114mm | PL | S35 |
| 135mm | T1.3 | 3' 3" | 6.2 lb | 6.8" | 114mm | PL | S35 |
| 150mm | T1.3 | 4' 11" | 8.8 lb | 8.3" | 134mm | PL | S35 |
— LENS SPECIFICATIONS—
